R TYPE FULLY AUTOMATIC CUBE SUGAR MACHINES



R TYPE FULLY AUTOMATIC MACHINE T.T.O.R-45 T.T.O.R-145 T.T.O.R-245 T.T.O.R-345 T.T.O.R-445
AUTOMATIC FILLING AVAILABLE AVAILABLE AVAILABLE AVAILABLE AVAILABLE
AUTOMATIC BOX BONDING AVAILABLE AVAILABLE AVAILABLE AVAILABLE AVAILABLE
AUTOMATIC BOX BONDING AVAILABLE AVAILABLE AVAILABLE AVAILABLE AVAILABLE
PRODUCTION AREA
LENGTH 30.0 M 37.0 M 39.5 M 43.0 M 55.0 M
WIDTH 7.00 M 8.00 M 10.00 M 10.00 M 10.00 M
HEIGHT 3.00 M 3.00 M 3.00 M 3.50 M 3.50 M
PERSONAL NUMBER 3 4 5 6 6
PATTERN 380 MM 405 MM 440 MM 500 MM 550 MM
COMPRESSION RATE 1.02 – 1.08 GR/CM3 1.02 – 1.08 GR/CM3 1.02 – 1.08 GR/CM3 1.02 – 1.08 GR/CM3 1.02 – 1.08 GR/CM3
CRYSTAL SUGAR DIMENSIONS 0.3 – 1 MM 0.3 – 1 MM 0.3 – 1 MM 0.3 – 1 MM 0.3 – 1 MM
BAKERY
TOP 5 8 10 12 14
LOWER OVEN CAN BE ADDED ACCORDING TO THE SUGAR MEASUREMENT OVEN CAN BE ADDED ACCORDING TO THE SUGAR MEASUREMENT OVEN CAN BE ADDED ACCORDING TO THE SUGAR MEASUREMENT OVEN CAN BE ADDED ACCORDING TO THE SUGAR MEASUREMENT OVEN CAN BE ADDED ACCORDING TO THE SUGAR MEASUREMENT
COOLER
DOUBLE 2 X 2, 4 FANS 2 X 3, 6 FANS 3X 3, 9 FANS 3X 3, 9 FANS 4 X 3, FANS
ELECTRIC
INSTALLED IN 1 HOUR 25 KV 40 KV 50 KV 60 KV 70 KV
CONSUMED 20 KV 30 KV 40 KV 50 KV 60 KV
WATER
1 DAILY 100 LT 125 LT 250 LT 500 LT 750 LT
MOISTURE RATIO AT THE PRODUCTION PLACE MAX 70 % MAX 70 % MAX 70 % MAX 70 % MAX 70 %
CAPACITY
1 HOUR BETWEEN 250-333 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 500-583 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 833-1041 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 1375-1540 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 1875-2083 KG (DEPENDING ON SUGAR MEASUREMENT)
24 HOURS BETWEEN 6000-8000 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 12000-14000 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 20000-25000 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 33000-37500 KG (DEPENDING ON SUGAR MEASUREMENT) BETWEEN 45000-50000 KG (DEPENDING ON SUGAR MEASUREMENT)
SUGAR CUBE TO BE PRODUCED PRODUCES 12000-16000 BOXES WHEN IT IS 500GR WHEN IT IS 500GR, IT PRODUCES 24000-28000 BOXES WHEN IT IS 500GR, IT PRODUCES 40000-50000 BOXES
PRODUCES 6000-8000 BOXES WHEN 1000GR IS PRODUCES 12000-14000 BOXES WHEN 1000GR IS PRODUCES 20000-25000 BOXES WHEN 1000GR PRODUCES 33000-37500 BOXES WHEN 1000GR WHEN 1000GR IS PRODUCES 45000-50000 BOXES
WATER QUALITY USED DRINKABLE DRINKABLE DRINKABLE DRINKABLE DRINKABLE
